KONNEX – Load securing

SKUImageNameWebbing widthMaterialFinishingBreaking Strength (BS)SummaryDescriptionhf:att:pa_produkt-typhf:att:pa_gurtbreitehf:att:pa_materialhf:att:pa_oberflaechehf:att:pa_bruchlast
70FP019
Cam buckle 12mm - 1.0kN
Cam buckle 12mm - 1.0kN12 mmZamak (ZP0410)Blue Chromated1.0 kN (100 daN)

Zinc die-cast cam buckle for indoor and outdoor use, suitable for 12 mm tension band.

70FP019 is our smallest cam buckle. It is made of die-cast zinc and is designed for webbing widths of up to 12 mm. At 0.011 kg, it is a lightweight among the cam buckles.klemmschloesser12-mmzamakblau-verzinkt100-dan-bs
70EP020
Cam buckle 20mm - 2.0kN
Cam buckle 20mm - 2.0kN20 mmZamak (ZP0410)Blanc2.0 kN (200 daN)

Cam buckle for 20 mm Lashing.

klemmschloesser20-mmzamakblank200-dan-bs
70ES020
Cam buckle 20mm - 2.0kN (black)
Cam buckle 20mm - 2.0kN (black)20 mmZamak (ZP0410)Cathodic dip coating (KTL) black2.0 kN (200 daN)

Black Cam buckle for 20 mm strap

klemmschloesser20-mmzamakktl-beschichtet-schwarz200-dan-bs
70AP025
Cam buckle Dualsafe 25mm - 2.5kN
Cam buckle Dualsafe 25mm - 2.5kN25 mmZamak (ZP0410)Blanc2.5 kN (250 daN)

Dualsafe – Cam buckle for 25 mm lashing.
Two springs for better clamping force / holding force.
Other color versions on request.

Our cam buckles from the series Dualsafe are a further development of a commercial clamp buckle.
We have extended this with another spring, the advantage: the clamping lever presses evenly on the webbing over the entire width. These clamp buckles offer you a very good price/performance ratio. Please ask for our pallet offers.
Other versions:
70AG025 – Cam buckle Dualsafe 25mm – 2,5kN (olive green)
70AS025 – Cam buckle Dualsafe 25mm – 2,5kN (black)

All our 25mm Cam buckles with a Breaking Strength of 2.5kN:

klemmschloesser25-mmzamakblank250-dan-bs
70AS025
Cam buckle Dualsafe 25mm - 2.5kN (black)
Cam buckle Dualsafe 25mm - 2.5kN (black)25 mmZamak (ZP0410)RAL colour2.5 kN (250 daN)

Cam buckle Dualsafe for 25 mm Lashing.
Cathodic dip coating (KTL) – RAL9005 (black)

The cam buckle 70AS025 is based on the article 70AP025. The cathodic dip coating (KTL) in the color RAL9005 (black) gives the article not only a better appearance, but also a more resistant surface. Upon customer request, we offer other RAL colors.

All our 25mm Cam buckles with a Breaking Strength of 2.5kN:

klemmschloesser25-mmzamakral-farbe250-dan-bs
70AP030
Double Cam buckle 25mm - 2.5kN
Double Cam buckle 25mm - 2.5kN25 mmZamak (ZP0410)Blanc2.5 kN (250 daN)

Double Cam buckle for 25 mm Lashing.

Load securing with a dual cam buckle: here, the loose ends of the webbing are each pulled past the clamping lever, tensioned by hand to an open end and fixed in place by the clamping levers installed in the dual cam buckle. In contrast to compression and tension ratchets, low pretensioning forces are achieved with a load securing system: dual cam buckle with lashing strap.

All our 25mm Cam buckles with a Breaking Strength of 2.5kN:

klemmschloesser25-mmzamakblank250-dan-bs
70AP060
Cam buckle 25mm - 4.5kN
Cam buckle 25mm - 4.5kN25 mmZamak (ZP0410)Blue Chromated4.5 kN (450 daN)

Cam buckle for 25 mm Lashing.

Cam buckle made from high-quality galvanised die-cast zinc. Developed for high demands, this cam buckle is the ideal solution for a wide range of applications. Designed for a 25 mm wide webbing strap, it not only offers an optimum fit, but also a high level of safety.
The breaking strength of 450 daN makes our buckle reliable and robust in any situation. Whether you use it for professional equipment, outdoor activities or everyday use.

We also carry this zinc die-cast cam buckle as a stainless steel cam buckle in our program:

klemmschloesser25-mmzamakblau-verzinkt450-dan-bs
70AX045
Cam buckle 25mm - 4.5kN (Inox)
Cam buckle 25mm - 4.5kN (Inox)25 mmInox4.5 kN (450 daN)

Stainless steel Cam buckle for 25 mm Lashing.

We also have this stainless steel cam buckle in our program as a zinc die-cast cam buckle:

klemmschloesser25-mmedelstahl450-dan-bs
70AP050
Cam buckle Dualsafe 25mm - 5.0kN
Cam buckle Dualsafe 25mm - 5.0kN25 mmZamak (ZP0410)Blanc5.0 kN (500 daN)

Dualsafe – Cam buckle for 25 mm lashing.
Two springs for better clamping force / holding force.
Other color versions on request.

Our Dualsafe cam buckles, Made by KONNEX are a further development of a cam buckle for 25 mm wide straps. We have improved the pressure point on the webbing by means of a second spring. The advantage is that the clamping lever presses evenly on the tension strap over the entire width.
This cam buckle lock offers you a very good price/performance ratio. Please ask for our pallet offers.
Other versions:
70AF050 – Cam buckle Dualsafe 25mm – 5,0kN (red)
70AS050 – Cam buckle Dualsafe 25mm – 5,0kN (black)
We will be pleased to submit you an offer for this also as a chrome-plated or nickel-plated version.

klemmschloesser25-mmzamakblank500-dan-bs
70AS050
Cam buckle Dualsafe 25mm - 5.0kN (black)
Cam buckle Dualsafe 25mm - 5.0kN (black)25 mmZamak (ZP0410)RAL colour5.0 kN (500 daN)

Cam buckle Dualsafe for 25 mm Lashing.
Cathodic dip coating (KTL) – RAL 9005 (black)

If a cam buckle in a special color is required, then you have come to the right place. We are happy to coat according to your wishes, such as the Dualsafe cam buckle shown here. We have provided this with a cathodic dip coating RAL9005 (cathodic dip coating, black). This surface protection not only gives the article a better appearance, but also a more resistant surface. On customer request even with your company logo.

klemmschloesser25-mmzamakral-farbe500-dan-bs
70AQ075
Cam buckle 25mm - 10kN
Cam buckle 25mm - 10kN25 mmHigh tensile steelBlue Chromated10 kN (1,000 daN)

Cam buckle for 25 mm Lashing.

Cam buckle body: Galvanized steel
Cam buckle handle: Zinc die-casting

klemmschloesser25-mmhochfester-stahlblau-verzinkt1000-dan-bs
70AQ080
Cam buckle 25mm - 8.0kN
Cam buckle 25mm - 8.0kN25 mmZamak (ZP0410)Blue Chromated8.0 kN (800 daN)

Zinc die-cast cam buckle for 25 mm Lashing.

A clamp buckle plays an important role in securing loads, especially when transporting goods on vehicles such as lorries, trailers or other means of transport. Load securing is crucial to prevent accidents, injuries and damage. The clamp buckle is an element used in this context to securely fix cargo.

Here are some specific functions and roles of a turnbuckle in load securing:

Fixing the load: clamp buckles are often used to fix pieces of cargo together. For example, they can be used to connect wooden beams, metal parts or other elements of the load together to prevent them from slipping or tipping over during transport.

Ease of use: Cam buckles are often designed to be easy to open and close. This facilitates the loading process and saves time while ensuring reliable securing.

Proper use of clamp buckles and other load securing devices is critical to ensure safety on the road and minimise potential hazards associated with unsecured cargo. It is important to follow local regulations and safety standards to ensure that the load meets the appropriate requirements.

klemmschloesser25-mmzamakblau-verzinkt800-dan-bs
70BP070
Cam buckle 35mm - 8.0kN
Cam buckle 35mm - 8.0kN35 mmZamak (ZP0410)Blue Chromated8.0 kN (800 daN)

Cam buckle for 35 mm Lashing.

The cam buckle is made of zinc die-cast (galvanized) and is suitable for indoor, but also for outdoor use.

klemmschloesser35-mmzamakblau-verzinkt800-dan-bs
70CQ100
Cam buckle 50mm - 14kN (Heavy Duty)
Cam buckle 50mm - 14kN (Heavy Duty)50 mmHigh tensile steelBlue Chromated14 kN (1,400 daN)

Cam buckle for 50 mm Lashing belt.

A cam buckle for heavy loads – the lever made of die-cast zinc and the housing made of high-strength steel.
Lashing possibilities with a 50 mm wide webbing strap possible. On request, we coat this cam buckle 70CQ100 in various RAL colors.

klemmschloesser50-mmhochfester-stahlblau-verzinkt1400-dan-bs
70CSV100
Cam buckle 50mm - 14kN (black, Heavy Duty)
Cam buckle 50mm - 14kN (black, Heavy Duty)50 mmHigh tensile steelRAL colour14 kN (1,400 daN)

Cam buckle for 50 mm Lashing belt.
Powder coated – RAL 9005 (black)

A special needs clamp lock has several features and characteristics that distinguish it from conventional clamp locks. Here are some factors and considerations that could be taken into account when selecting or designing such a clamp lock:
Material and durability: the lock should be made of high quality and durable material to withstand the special requirements.
Load capacity: the clamp lock should be able to withstand heavy loads and vibrations, depending on the requirements of the application. This could be relevant for applications in heavy industry, mining or transportation.
Temperature resistance: If the clamp lock is exposed to extreme temperatures, it should be able to withstand these conditions without compromising its function or strength.
Security: Depending on the application, additional security features might be required, such as a secure locking mechanism.
Weather resistance: If the clamp lock is used outdoors, it should be weatherproof and able to withstand the effects of rain, snow and UV radiation.
Adaptability: a special needs clamp lock should potentially be adaptable to different mounting points or configurations to meet specific needs.
Approvals and certifications: Depending on the application, special approvals or certifications could be required to ensure the lock meets applicable standards.
The specific requirements for a clamp lock will depend on the application. It is important to clarify these requirements in advance and, if necessary, work with a professional or a company that specializes in the design and manufacture of specialized locks for specific applications.

klemmschloesser50-mmhochfester-stahlral-farbe1400-dan-bs
72AX008
J-Hook 25mm - 8kN (53mm)
J-Hook 25mm - 8kN (53mm)25 mmInox8.0 kN (800 daN)

With a length of 53 mm, this stainless steel pointed hook / double finger hook is designed for use that requires special requirements.

In conjunction with a stainless steel pressure ratchet is a perfect combination. A 25 mm wide tension band is used.

spitzhaken25-mmedelstahl800-dan-bs
72AQ002
J-Hook 25mm - 10kN (47mm)
J-Hook 25mm - 10kN (47mm)25 mmHigh tensile steelBlue Chromated10 kN (1,000 daN)

J-Hook / Double finger hook for 25 mm Lashing.
Length: 47 mm

spitzhaken25-mmhochfester-stahlblau-verzinkt1000-dan-bs
72AQ001
J-Hook 25mm - 15kN (50mm)
J-Hook 25mm - 15kN (50mm)25 mmHigh tensile steelBlue Chromated – KOsil15 kN (1,500 daN)

J-Hook / Double finger hook for 25 mm .
Length: 55 mm

A profile hook is a practical companion in the field of load securing, it is quickly used and is designed for bandwidth of 25 mm.

spitzhaken25-mmhochfester-stahlblau-verzinkt-kosil1500-dan-bs
72BQ012
J-Hook 35mm - 30kN (65mm)
J-Hook 35mm - 30kN (65mm)35 mmHigh tensile steelBlue Chromated30 kN (3,000 daN)

J-Hook / Double finger hook for 35 mm Lashing.
Length: 65 mm

A j-hook or profile hook, is ideal for securing loads on a truck and van.
This profile hook is suitable for 35 mm lashing straps.

spitzhaken35-mmhochfester-stahlblau-verzinkt3000-dan-bs
72BX030
J-Hook 35mm - 30kN (74mm)
J-Hook 35mm - 30kN (74mm)35 mmInox30 kN (3,000 daN)

J-Hook / Double finger hook for 35 mm Lashing.
Length: 74 mm

spitzhaken35-mmedelstahl3000-dan-bs
72BQ002
J-Hook 35mm - 30kN (84mm)
J-Hook 35mm - 30kN (84mm)35 mmHigh tensile steelBlue Chromated30 kN (3,000 daN)

J-Hook / Double finger hook for 35 mm Lashing.
Length: 84 mm

spitzhaken35-mmhochfester-stahlblau-verzinkt3000-dan-bs
72BQ013
J-Hook 35mm - 30kN (87mm)
J-Hook 35mm - 30kN (87mm)35 mmHigh tensile steelBlue Chromated30 kN (3,000 daN)

J-Hook / Double finger hook for 35 mm Lashing, with Safety latch.
Length: 87 mm

spitzhaken35-mmhochfester-stahlblau-verzinkt3000-dan-bs
72BQ003
J-Hook 35mm - 30kN (91mm)
J-Hook 35mm - 30kN (91mm)35 mmHigh tensile steelBlue Chromated30 kN (3,000 daN)

J-Hook / Finger hook for 35 mm Lashing.
Length: 91 mm

spitzhaken35-mmhochfester-stahlblau-verzinkt3000-dan-bs
72CQ300
J-Hook 50mm - 50kN (74mm)
J-Hook 50mm - 50kN (74mm)50 mmHigh tensile steelBlue Chromated – KOsil50 kN (5,000 daN)

J-Hook / Double finger hook short, for 50 mm Lashing belt.
Length: 74 mm

*** Very high corrosion protection due to our KOsil – passivation ***

A swivel hook or profile hook, double finger hook is ideal for securing loads in trucks and vans.
This standard swivel hook 72CQ300 is suitable for 50 mm tension webbing.

spitzhaken50-mmhochfester-stahlblau-verzinkt-kosil5000-dan-bs
72CQ003
J-Hook 50mm - 50kN (74mm)
J-Hook 50mm - 50kN (74mm)50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

J-Hook / Double finger hook short, for 50 mm Lashing belt.
Length: 74 mm

A swivel hook or profile hook, double finger hook is ideal for securing loads in trucks and vans.
This standard swivel hook 72CQ003 is suitable for 50 mm tension webbing.

spitzhaken50-mmhochfester-stahlblau-verzinkt5000-dan-bs
72CQ301
J-Hook 50mm - 50kN (magnetic)
J-Hook 50mm - 50kN (magnetic)50 mmHigh tensile steelBlue Chromated – KOsil50 kN (5,000 daN)

J-Hook / double finger hook short for 50 mm lashing strap with with integrated magnet for better grip.
High corrosion protection due to our KOsil coating.

Simplified lashing of the load: the magnetic J-Hook (72CQ301) remains in its intended position after hooking.
There is no decoupling and the load securing process is not interrupted until the load is finally secured.
The integrated magnet prevents the pointed J-Hook from coming loose from the anchoring eyelet on the floor of the loading area.
Easy load securing on a truck or van.

spitzhaken50-mmhochfester-stahlblau-verzinkt-kosil5000-dan-bs
72CX050
J-Hook 50mm - 50kN (85mm)
J-Hook 50mm - 50kN (85mm)50 mmInox50 kN (5,000 daN)

J-Hook / Double finger hook – for 50 mm Lashing belt.
Length: 85 mm

spitzhaken50-mmedelstahl5000-dan-bs
72CQ014
J-Hook 50mm - 50kN (96mm)
J-Hook 50mm - 50kN (96mm)50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

J-Hook / Double finger hook for 50 mm Lashing belt, with Safety latch.
Length: 96 mm

A profile hook with a spring-loaded sheet metal trap, the use is with a 50 mm wide webbing.
The sheet metal trap ensures that the profile hook does not jump out of the lashing.

spitzhaken50-mmhochfester-stahlblau-verzinkt5000-dan-bs
72CQ008
J-Hook 50mm - 50kN (107mm)
J-Hook 50mm - 50kN (107mm)50 mmHigh tensile steelBlue Chromated – KOsil50 kN (5,000 daN)

J-Hook / Double finger hook for 50 mm Lashing belt. Length: 107 mm

J-Hook is also called a double finger hook, it can be used in many ways and is very suitable for securing loads on a truck trailer or in the van.
Our hooks are made of high quality steel and galvanized CrVI-free.
In combination with a pressure ratchet or an ERGO ratchet, these are the perfect unit to ensure safety in transportation.

More hooks for webbing dimensions from 25 mm up to 75 mm can be found in our OnlineShop.

spitzhaken50-mmhochfester-stahlblau-verzinkt-kosil5000-dan-bs
72CQ052
J-Hook 50mm - 50kN (110mm)
J-Hook 50mm - 50kN (110mm)50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

J-Hook / Double finger hook for 50 mm Lashing belt, with Safety latch.
Length: 110 mm

spitzhaken50-mmhochfester-stahlblau-verzinkt5000-dan-bs
72CQ006
J-Hook 50mm - 50kN (133mm)
J-Hook 50mm - 50kN (133mm)50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

J-Hook / Finger hook for 50 mm Lashing belt.
Length: 133 mm

spitzhaken50-mmhochfester-stahlblau-verzinkt5000-dan-bs
72CQ042
J-Hook with bridge 50mm - 50kN (134mm)
J-Hook with bridge 50mm - 50kN (134mm)50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

J-Hook / Double finger hook for 50 mm Lashing belt, with Bridge.
Length: 134 mm

Load securing with a double web hook in conjunction with a lashing strap is also known as a one-way tensioning strap.
This is an inexpensive alternative to a tension belt system with a compression or tension ratchet.

spitzhaken50-mmhochfester-stahlblau-verzinkt5000-dan-bs
72CQ012
J-Hook with tube 50mm - 50kN (158mm)
J-Hook with tube 50mm - 50kN (158mm)50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

J-Hook / Finger hook for 50 mm Lashing belt, with tube. Length: 158 mm

Single-finger profile hook for direct connection to a push or pull ratchet – as a fixed end.
Steel tube welded on

spitzhaken50-mmhochfester-stahlblau-verzinkt5000-dan-bs
72DQ002
J-Hook 75mm - 100kN (135mm)
J-Hook 75mm - 100kN (135mm)75 mmHigh tensile steelBlue Chromated100 kN (10,000 daN)

J-Hook / Double finger hook for 75 mm Lashing belt.

J-Hook are also called profile hooks and are used to attach lashing straps to lashing points or to external frame hole profiles of the vehicle.

spitzhaken75-mmhochfester-stahlblau-verzinkt10000-dan-bs
72BQ001
Claw Hook 35mm - 30kN (open)
Claw Hook 35mm - 30kN (open)35 mmHigh tensile steelBlue Chromated30 kN (3,000 daN)

Claw hook for 35 mm Lashing belt, open version.

Our claw hooks include a strap width of 35 mm and is used in conjunction with a pressure ratchet when securing loads.

klauenhaken35-mmhochfester-stahlblau-verzinkt3000-dan-bs
72CQ002
Claw Hook 50mm - 50kN (open)
Claw Hook 50mm - 50kN (open)50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

Claw hook for 50 mm Lashing belt, open version.

Another aid in load securing is the claw hook, this end fitting is used with a two-piece lashing strap.
We have these for the following strap widths for you in the offer: 25 mm, 35 mm, 50 mm and 75 mm.

klauenhaken50-mmhochfester-stahlblau-verzinkt5000-dan-bs
72AQ009
Flat Hook 25mm - 15kN
Flat Hook 25mm - 15kN25 mmHigh tensile steelBlue Chromated15 kN (1,500 daN)

Flat hook / Pallet hook for 25 mm Lashing belt.

flachhaken25-mmhochfester-stahlblau-verzinkt1500-dan-bs
72AQ011
Flat Hook 25mm - 15kN (with Safety device)
Flat Hook 25mm - 15kN (with Safety device)25 mmHigh tensile steelBlue Chromated15 kN (1,500 daN)

Flat hook / Pallet hook for 25 mm Lashing, with Safety device.

Flat hook with spring-loaded safety pin, this prevents loosening from a lashing rail, this is used with a width of 25 mm.

flachhaken25-mmhochfester-stahlblau-verzinkt1500-dan-bs
72AQ012
Flat Hook 25mm - 15kN (without Safety device)
Flat Hook 25mm - 15kN (without Safety device)25 mmHigh tensile steelBlue Chromated15 kN (1,500 daN)

Flat hook for 25 mm Lashing, without Safety device.

flachhaken25-mmhochfester-stahlblau-verzinkt1500-dan-bs
72CQ029
Flat Hook 50mm - 20kN
Flat Hook 50mm - 20kN50 mmHigh tensile steelBlue Chromated – KOsil20 kN (2,000 daN)

Flat hook / Pallet hook for 50 mm Lashing belt.

Flat hook made of high-strength steel for load securing for 50 mm webbing.

flachhaken50-mmhochfester-stahlblau-verzinkt-kosil2000-dan-bs
72CQ009
Flat Hook 50mm - 50kN (115mm)
Flat Hook 50mm - 50kN (115mm)50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

Flat hook / Pallet hook for 50 mm Lashing belt.
Length: 115 mm

A flat hook or heavy profile hook has been developed for securing loads in lorries and vans.
Forged version, designed for lashing strap widths of 50 mm.

A “flat hook” in load securing could be used in various ways, depending on the type of load, the means of transport and the specific requirements. Here are some possible applications:
Connection with lashing straps: flat hooks serve as end fittings for lashing straps. These straps are placed around the load and then secured by the flat hook to hold the load in place.
Special applications: Depending on the specific requirements of the load and the transport, flat hooks may also have been developed for special applications, e.g. for transporting construction site materials or other heavy goods.
Anchor point for nets: In some cases, flat hooks are used to attach safety nets or covers over the load. These nets are used to prevent loose parts of the load from falling during transport.

flachhaken50-mmhochfester-stahlblau-verzinkt5000-dan-bs
72CQ035
Flat Hook 50mm - 50kN (revolving)
Flat Hook 50mm - 50kN (revolving)50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

Flat hook for 50 mm Lashing straps, revolving.

Hook for Sommer / Ackermann-Frühauf-System – revolving

flachhaken50-mmhochfester-stahlblau-verzinkt5000-dan-bs
72AQ008
Triangle Load Hook 25mm - 25kN (Latch)
Triangle Load Hook 25mm - 25kN (Latch)25 mmHigh tensile steelBlue Chromated25 kN (2,500 daN)

Forged and galvanized triangle snap hook / load hook for 25 mm tension band.
Design: with sheet metal latch

karabinerhaken25-mmhochfester-stahlblau-verzinkt2500-dan-bs
72AQ010
Triangle Load Hook 25mm - 25kN (Spring)
Triangle Load Hook 25mm - 25kN (Spring)25 mmHigh tensile steelBlue Chromated25 kN (2,500 daN)

Forged and galvanized triangle snap hook / load hook for 25 mm tension band.
Design: with wire latch.

karabinerhaken25-mmhochfester-stahlblau-verzinkt2500-dan-bs
72AQ018
Load Hook 25mm - 25kN (Latch)
Load Hook 25mm - 25kN (Latch)25 mmHigh tensile steelBlue Chromated25 kN (2,500 daN)

Load hook for 25 mm Lashing, with Safety latch.

A simple and uncomplicated form of load securing in a van is the use of a load securing net.
This is placed over the load to be secured and hooked into e.g. lashing recesses, D-ring or U-bolts by means of the snap hook sewn to the lashing strap.

The load hooks have a safety device against loosening, which is designed in the form of a sheet metal trap or a wire trap.

72AQ018 Load hook 25mm – 25kN (with latch)
72AQ019 Load hook 25mm – 25kN (with spring)

karabinerhaken25-mmhochfester-stahlblau-verzinkt2500-dan-bs
72AQ019
Load Hook 25mm - 25kN (Spring)
Load Hook 25mm - 25kN (Spring)25 mmHigh tensile steelBlue Chromated25 kN (2,500 daN)

Load hook for 25 mm Lashing, with Safety spring.

karabinerhaken25-mmhochfester-stahlblau-verzinkt2500-dan-bs
72BQ007
Load Hook 35mm - 30kN (twisted)
Load Hook 35mm - 30kN (twisted)35 mmHigh tensile steelBlue Chromated – KOsil30 kN (3,000 daN)

Snap hook / Flat hook for 35 mm Lashing, twisted, with Safety latch.
Length: 130 mm

karabinerhaken35-mmhochfester-stahlblau-verzinkt-kosil3000-dan-bs
72CQ004
Snap Hook 50mm - 50kN
Snap Hook 50mm - 50kN50 mmHigh tensile steelBlue Chromated – KOsil50 kN (5,000 daN)

Snap hook / Flat hook for 50 mm Lashing belt, with Safety latch.

karabinerhaken50-mmhochfester-stahlblau-verzinkt-kosil5000-dan-bs
72CQ005
Snap Hook 50mm - 50kN (twisted)
Snap Hook 50mm - 50kN (twisted)50 mmHigh tensile steelBlue Chromated – KOsil50 kN (5,000 daN)

Snap hook / Flat hook for 50 mm Lashing belt, with Safety latch, twisted.

karabinerhaken50-mmhochfester-stahlblau-verzinkt-kosil5000-dan-bs
72CQ001
Triangle Load Hook 50mm - 50kN (Latch)
Triangle Load Hook 50mm - 50kN (Latch)50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

Triangle load hook for 50 mm Lashing straps, with Safety latch.

karabinerhaken50-mmhochfester-stahlblau-verzinkt5000-dan-bs
72DQ003
Triangle Load Hook 75mm - 100kN (Latch)
Triangle Load Hook 75mm - 100kN (Latch)75 mmHigh tensile steelBlue Chromated100 kN (10,000 daN)

Triangle load hook for 75 mm Lashing belt, with Safety latch.
Opening: 30 mm

karabinerhaken75-mmhochfester-stahlblau-verzinkt10000-dan-bs
72BQ009
Swivel J-Hook 35mm - 30kN (100mm)
Swivel J-Hook 35mm - 30kN (100mm)35 mmHigh tensile steelBlue Chromated30 kN (3,000 daN)

Swivel Hook for 35 mm Ratchet, without bolt.
Length: 100 mm

This swivel hook is mounted as a fixed end on a pressure ratchet.
A swivel hook is a special form of hook that is used in various applications, including load securing. The name “swivel hook” is derived from the hook’s ability to rotate or swivel on its own axis. This mechanism enables more flexible adjustment and facilitates handling in various situations.

In load securing, the swivel hook is often attached to one end of a lashing strap or lashing chain. The swivelling head of the hook offers more flexibility when attaching to different anchor points or fixing points. This can be particularly useful when the direction of the pulling angle can vary.

The advantages of a swivel hook in load securing can be

Flexibility: the swivelling head of the hook allows better adaptation to different angles and surfaces.

Reduction of twisting: The ability of the swivel hook to rotate on its own axis minimises the risk of twisting of the tensioning strap or lashing chain, which contributes to safer load securing.

Easier handling: The movable head makes it easier to attach the hook to different anchoring points, which makes the entire load securing process more efficient.

wirbelhaken35-mmhochfester-stahlblau-verzinkt3000-dan-bs
72BQ006
Swivel J-Hook 35mm - 30kN (117mm)
Swivel J-Hook 35mm - 30kN (117mm)35 mmHigh tensile steelBlue Chromated30 kN (3,000 daN)

Swivel Hook for 35 mm Lashing straps, with nut and bolt.
Length: 117 mm

wirbelhaken35-mmhochfester-stahlblau-verzinkt3000-dan-bs
72CQ033
Swivel J-Hook 50mm - 50kN (105mm)
Swivel J-Hook 50mm - 50kN (105mm)50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

Swivel Hook for 50 mm Ratchet, without bolt. Length: 105 mm

Dieser Wirbelhaken wird als Festende bei einer Druck- oder Zugratsche montiert.

wirbelhaken50-mmhochfester-stahlblau-verzinkt5000-dan-bs
72CQ016
Swivel J-Hook 50mm - 50kN (106mm)
Swivel J-Hook 50mm - 50kN (106mm)50 mmHigh tensile steelBlue Chromated – KOsil50 kN (5,000 daN)

Swivel Hook with sleeve for 50 mm Ratchet, with nut and bolt.
Length: 106 mm

wirbelhaken50-mmhochfester-stahlblau-verzinkt-kosil5000-dan-bs
72AQ013
Pallet hook 25mm - 1.0kN (closed)
Pallet hook 25mm - 1.0kN (closed)25 mmSteelTransparent Passivated1.0 kN (100 daN)

Pallet hooks are designed for securing light loads.
Design: closed for 25 mm tension band

haken-weiteres25-mmnormalstahltransparent-passiviert100-dan-bs
72ASQ005
S-Hook 25mm - 5kN
S-Hook 25mm - 5kN25 mmSteelBlue Chromated, Combination5.0 kN (500 daN)

S-hook, black PVC coated.
In conjunction with a 25 mm ratchet, it is a simple way of securing a load.

haken-weiteres25-mmnormalstahlblau-verzinkt kombination500-dan-bs
72AQ003
Triangle 25mm - 25kN
Triangle 25mm - 25kN25 mmHigh tensile steelBlue Chromated25 kN (2,500 daN)

Triangle / Delta Bracket for 25 mm lashing strap.

triangel25-mmhochfester-stahlblau-verzinkt2500-dan-bs
72BQ011
Triangle 35mm - 30kN
Triangle 35mm - 30kN35 mmHigh tensile steelBlue Chromated30 kN (3,000 daN)

Triangle for 35 mm lashing strap.

An isosceles butt welded triangle for 35 mm webbing.
One of our end fittings that are used for securing loads.

triangel35-mmhochfester-stahlblau-verzinkt3000-dan-bs
72CQ011
Triangle 50mm - 50kN
Triangle 50mm - 50kN50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

Triangle for 50 mm webbing.

A closed, isosceles triangle for 50 mm webbing.
End fitting for cargo securing.

triangel50-mmhochfester-stahlblau-verzinkt5000-dan-bs
72CQ054
Triangel 50mm - 50kN (forged)
Triangel 50mm - 50kN (forged)50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

A closed, isosceles forged triangle for 50 mm webbing.
End fitting for securing loads.

Forged design and its advantages:
– no weld seam
– dimensional accuracy
– high strength
– high static and dynamic load capacity

50-mmhochfester-stahlblau-verzinkt5000-dan-bs
72DQ004
Belt Shackle 75mm - 120kN
Belt Shackle 75mm - 120kN75 mmHigh tensile steelBlue Chromated120 kN (12,000 daN)

Belt shackle, to be used as an end fitting for a load securing system with a strap width of 75 mm and an LC of 6,000 daN.

bandbuegel75-mmhochfester-stahlblau-verzinkt12000-dan-bs
72DQ005
Belt Shackle 75mm - 200kN
Belt Shackle 75mm - 200kN75 mmHigh tensile steelBlue Chromated200 kN (20,000 daN)

Belt shackle, to be used as an end fitting for a load securing system with a strap width of 75 mm and an LC of 10,000 daN.

bandbuegel75-mmhochfester-stahlblau-verzinkt20000-dan-bs
71AQ008
Pressure Ratchet 25mm - 8kN
Pressure Ratchet 25mm - 8kN25 mmHigh tensile steelBlue Chromated – KOsil8.0 kN (800 daN)

Our smallest pressure ratchet for a 25mm wide webbing, universally applicable for lighter loads.

With an LC of 400 daN in straight pull, this Hobby ratchet is one of the smallest in our range. With a strap width of 25 mm, different loads can be secured. The 71AQ008 is a pressure ratchet without lever safety device, the tensioning movement during load securing always goes in the direction of the loose end.

All our 25mm Pressure Ratchets with a Breaking Strength of 8kN:

druckratschen25-mmhochfester-stahlblau-verzinkt-kosil800-dan-bs
71ASQ008
Pressure Ratchet 25mm - 8kN (bicolor)
Pressure Ratchet 25mm - 8kN (bicolor)25 mmHigh tensile steelRAL colour8.0 kN (800 daN)

Pressure ratchet for 25 mm webbing, without Lever lock.
RAL9005 (black)

This black (black/silver) Hobby ratchet with an LC of 400 daN in straight pull is one of the smallest in our range. This is used with a 25 mm wide webbing.

All our 25mm Pressure Ratchets with a Breaking Strength of 8kN:

druckratschen25-mmhochfester-stahlral-farbe800-dan-bs
71AX008
Pressure Ratchet 25mm - 8kN (Inox)
Pressure Ratchet 25mm - 8kN (Inox)25 mmInox8.0 kN (800 daN)

Pressure ratchet / Hobby ratchet for 25 mm Lashing straps.

With an LC of 400 daN in straight pull, this stainless steel Hobby ratchet is one of the smallest in our range. With a strap width of 25 mm, different loads can be secured.

All our 25mm Pressure Ratchets with a Breaking Strength of 8kN:

druckratschen25-mmedelstahl800-dan-bs
71AQ015
25mm-Druckratsche-stahl
Pressure Ratchet 25mm - 15kN25 mmHigh tensile steelBlue Chromated15 kN (1,500 daN)

Pressure ratchet for 25 mm Lashing.
Handgrip: steel, wide version

druckratschen25-mmhochfester-stahlblau-verzinkt1500-dan-bs
71AX015
Pressure Ratchet 25mm - 15kN (Inox)
Pressure Ratchet 25mm - 15kN (Inox)25 mmInox15 kN (1,500 daN)

Pressure ratchet for 25 mm Lashing.
Handgrip: wide, Inox

Load securing with ease and precision!
Our article number 71AX015 is a first-class 25 mm stainless steel (inox) pressure ratchet – your reliable solution for safe transport.
With a breaking load of 15 kN, this small but powerful ratchet offers maximum safety.

The wide handle ensures comfortable handling, while the stainless steel construction stands for robustness and durability.
This pressure ratchet is ideal for securing loads firmly and reliably, whether for commercial transport or private use.

You can rely on the highest quality and efficiency.

druckratschen25-mmedelstahl1500-dan-bs
71BX015
Pressure Ratchet 35mm - 15kN (Inox)
Pressure Ratchet 35mm - 15kN (Inox)35 mmInox15 kN (1,500 daN)

Pressure ratchet for 35 mm Lashing.
Handgrip: wide, Inox

druckratschen35-mmedelstahl1500-dan-bs
71BQ020
Pressure Ratchet 35mm - 20kN (137mm)
Pressure Ratchet 35mm - 20kN (137mm)35 mmHigh tensile steelBlue Chromated – KOsil20 kN (2,000 daN)

Pressure ratchet for 35 mm Lashing.
Handgrip: wide, steel

druckratschen35-mmhochfester-stahlblau-verzinkt-kosil2000-dan-bs
71BQ031
Pressure Ratchet 35mm - 30kN
Pressure Ratchet 35mm - 30kN35 mmHigh tensile steelBlue Chromated30 kN (3,000 daN)

Pressure ratchet with Lever lock for 35 mm webbing.

druckratschen35-mmhochfester-stahlblau-verzinkt3000-dan-bs
71BQ030
Pressure Ratchet 35mm - 30kN (Plastic Handgrip)
Pressure Ratchet 35mm - 30kN (Plastic Handgrip)35 mmHigh tensile steelBlue Chromated30 kN (3,000 daN)

Pressure ratchet with Lever lock for 35 mm webbing.
Handgrip: narrow, steel

Our 35mm pressure ratchet is often used to secure loads in a van, car or on a car trailer.
It is equipped with a user-friendly plastic handle and a lever lock

druckratschen35-mmhochfester-stahlblau-verzinkt3000-dan-bs
71BSQ030
Pressure Ratchet 35mm - 30kN (bicolor, Plastic Handgrip)
Pressure Ratchet 35mm - 30kN (bicolor, Plastic Handgrip)35 mmHigh tensile steelRAL colour30 kN (3,000 daN)

Pressure ratchet with Lever lock for 35 mm webbing.
RAL9005 (black)
Handgrip: wide, plastic

druckratschen35-mmhochfester-stahlral-farbe3000-dan-bs
71BQ033
Pressure Ratchet 35mm - 30kN (STF 330 daN)
Pressure Ratchet 35mm - 30kN (STF 330 daN)35 mmHigh tensile steelBlue Chromated30 kN (3,000 daN)

Pressure ratchet with lever safety catch for 35 mm tensioning strap with an STF value of 330 daN.

Discover our latest 35 mm pressure ratchet.
Developed to revolutionise the securing of cars on vans! Our 35 mm pressure ratchet is based on a thorough development and offers safety for the transport of vehicles.
With a secured STF value of 330 daN, our pressure ratchet is designed to ensure maximum safety even under extreme conditions. The ratchet has been tested in accordance with the specifications of DIN EN 12195-2 – for absolute reliability and quality. Rely on our pressure ratchet to securely and safely fasten your cars to the transporter. It is a reliable solution for a trouble-free and safe transport experience.
Your safety is our top priority!
Move with the future of car securing – with our 71BQ033 pressure ratchet!

VDI Guideline 2700 Sheet 1 – “Load securing on road vehicles”
This guideline provides guidelines and recommendations for the safe securing of loads during transport on road vehicles. Here are some key aspects that can be covered in the guideline:
Objective: the aim of the guideline is to ensure road safety by providing guidance on the correct securing of loads on vehicles. This is important to prevent accidents that could be caused by unsecured or improperly secured loads.
Responsibilities: The guideline could encourage the various parties in the transport process (such as the shipper, carrier, driver, etc.) to take on certain responsibilities in relation to load securing.
Calculation of securing forces: Methods and formulas can be provided to calculate the required securing forces for the different types of cargo and means of transport.
Securing equipment: The guideline could provide recommendations for suitable securing equipment such as lashing straps, anti-slip mats or other aids to effectively secure the load.
Testing and documentation: Instructions may be included for carrying out load securing tests before and during transport and for documenting the securing measures carried out.

druckratschen35-mmhochfester-stahlblau-verzinkt3000-dan-bs
71BX031
Pressure Ratchet 35mm - 30kN (Inox)
Pressure Ratchet 35mm - 30kN (Inox)35 mmInox30 kN (3,000 daN)

Pressure ratchet with Lever lock, for 35 mm webbing.
Handgrip: wide, Inox

druckratschen35-mmedelstahl3000-dan-bs
74BQ000
Pressure Ratchet 35mm - 30kN (wide, J-Hook)
Pressure Ratchet 35mm - 30kN (wide, J-Hook)35 mmHigh tensile steelBlue Chromated30 kN (3,000 daN)

Pressure ratchet with Lever lock for 35 mm webbing.
J-Hook / Finger hook: mounted

Set:

druckratschen35-mmhochfester-stahlblau-verzinkt3000-dan-bs
74BQ002
Pressure Ratchet 35mm - 30kN (narrow, Swivel Hook)
Pressure Ratchet 35mm - 30kN (narrow, Swivel Hook)35 mmHigh tensile steelBlue Chromated30 kN (3,000 daN)

Pressure ratchet with Lever lock for 35 mm webbing.
Handgrip: plastic, narrow version
Swivel J-Hook: mounted

druckratschen35-mmhochfester-stahlblau-verzinkt3000-dan-bs
74BQ003
Pressure Ratchet 35mm - 30kN (narrow, J-Hook)
Pressure Ratchet 35mm - 30kN (narrow, J-Hook)35 mmHigh tensile steelBlue Chromated30 kN (3,000 daN)

Pressure ratchet with Lever lock for 35 mm webbing.
J-Hook / Double finger hook: mounted

Handgrip: narrow, steel

Set:

druckratschen35-mmhochfester-stahlblau-verzinkt3000-dan-bs
74BQ004
Pressure Ratchet 35mm - 30kN (wide, Swivel Hook)
Pressure Ratchet 35mm - 30kN (wide, Swivel Hook)35 mmHigh tensile steelBlue Chromated30 kN (3,000 daN)

Pressure ratchet with Lever lock for 35 mm webbing.
Swivel J-Hook: mounted

Set:

druckratschen35-mmhochfester-stahlblau-verzinkt3000-dan-bs
74BQ005
Pressure Ratchet 35mm - 30kN (wide, Swivel Hook long)
Pressure Ratchet 35mm - 30kN (wide, Swivel Hook long)35 mmHigh tensile steelBlue Chromated30 kN (3,000 daN)

Pressure ratchet with Lever lock for 35 mm webbing. Swivel J-Hook: mounted Set: Swivel J-Hook (long) 35mm – 30kN Pressure Ratchet 35mm – 30kN

druckratschen35-mmhochfester-stahlblau-verzinkt3000-dan-bs
71CQ020
Pressure Ratchet 50mm - 20kN
Pressure Ratchet 50mm - 20kN50 mmHigh tensile steelBlue Chromated – KOsil20 kN (2,000 daN)

Pressure ratchet for 50 mm Lashing belt.
Handgrip: wide, steel

Short pressure ratchet, with a length of 134 mm it is one of the smallest in our delivery program in the range of 50 mm webbing.

druckratschen50-mmhochfester-stahlblau-verzinkt-kosil2000-dan-bs
71CX020
Pressure Ratchet 50mm - 20kN (Inox)
Pressure Ratchet 50mm - 20kN (Inox)50 mmInox20 kN (2,000 daN)

Stainless steel pressure ratchet in a short version for 50 mm lashing straps.
Ratchet handle: stainless steel, wide version

druckratschen50-mmedelstahl2000-dan-bs
71CX035
Pressure Ratchet 50mm - 40kN (Inox)
Pressure Ratchet 50mm - 40kN (Inox)50 mmInox40 kN (4,000 daN)

Pressure ratchet with Lever lock for 50 mm webbing.

druckratschen50-mmedelstahl4000-dan-bs
72CQ050
Pressure ratchet body 50mm - 50kN
Pressure ratchet body 50mm - 50kN50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

Pressure ratchet body for 50 mm Lashing belt, with hexagon (SW28) socket.

Pressure ratchet body / pressure ratchet without operating lever with hexagonal socket (SW28) as drive, for 50 mm lashing strap.

druckratschen50-mmhochfester-stahlblau-verzinkt5000-dan-bs
71CQ050
Pressure Ratchet 50mm - 50kN (188mm)
Pressure Ratchet 50mm - 50kN (188mm)50 mmHigh tensile steelBlue Chromated – KOsil50 kN (5,000 daN)

The one with the red handle – our standard pressure ratchet with lever lock for 50 mm lashing strap.
Handle design: plastic, red
Lever length: 188 mm

Our standard pressure ratchet 71CQ050 is used on a truck or van. In connection with belt strap and end fittings, it secures your load against slipping and holds it in the intended place on the loading area.

druckratschen50-mmhochfester-stahlblau-verzinkt-kosil5000-dan-bs
71CQ052
Pressure ratchet 50mm - 50kN (190mm)
Pressure ratchet 50mm - 50kN (190mm)50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

Pressure ratchet with lever safety device for 50 mm lashing strap.
Handle design: black plastic
Lever length: 190 mm

Pressure ratchet 71CQ052 with rubberized operating parts (lever, lever lock).
With webbing and end fittings, it secures your load against slipping and keeps it in the intended place on the loading area.

druckratschen50-mmhochfester-stahlblau-verzinkt5000-dan-bs
71CQ059
Pressure Ratchet 50mm - 50kN (213mm)
Pressure Ratchet 50mm - 50kN (213mm)50 mmHigh tensile steelBlue Chromated – KOsil50 kN (5,000 daN)

NEW – the one with the red handle, our pressure ratchet for 50 mm lashing strap.
Special feature: higher STF value than the standard pressure ratchet.
Handle design: plastic, red
Lever length: 213 mm

With the red handle – Our new pressure ratchet 71CQ059 with higher STF value.
Used on a truck or van. In conjunction with webbing and end fittings, it secures your load against slipping and holds it in the intended place on the loading area.

druckratschen50-mmhochfester-stahlblau-verzinkt-kosil5000-dan-bs
8AQ25S050501WO00
Roll up - System 25mm
Roll up - System 25mm25 mmHigh tensile steelBlue Chromated7.0 kN (700 daN)

SELF-LOCK
With a roll up system your load is quickly secured. No cumbersome insertion of the webbing into the winding shaft, no free-hanging webbing after securing the load. Particularly easy to use. Due to the automatic retractor, the webbing is slightly under tension during the securing process. If the webbing is rewound too quickly, e.g. if the end fittings are released, the system is blocked by the safety rewind lock in the rewind spool by means of a locking lever, thus preventing injuries caused by whirling end fittings, and the webbing is rewound in a controlled manner.

• the safest and smartest retractable ratchet harness in the world
• the most automatic retractable harness in the world, certified by TÜV / GS
• fast, easy and safe to use
• built-in spring automatically retracts the webbing for easy storage
• built-in self-locking mechanism to control the retraction speed
• safety retraction lock when the retraction speed is too fast, the best protection for the user
• strong and abrasion-resistant polyester webbing

druckratschen25-mmhochfester-stahlblau-verzinkt700-dan-bs
8BQ35S030500WO00
Roll up - System 35mm (with theft protection)
Roll up - System 35mm (with theft protection)35 mmHigh tensile steelBlue Chromated20 kN (2,000 daN)

SELF-LOCK
With a roll up system your load is quickly secured. No cumbersome insertion of the webbing into the winding shaft, no free-hanging webbing after securing the load. Particularly easy to use. Due to the automatic retractor, the webbing is slightly under tension during the securing process. If the webbing is rewound too quickly, e.g. if the end fittings are released, the system is blocked by the safety rewind lock in the rewind spool by means of a locking lever, thus preventing injuries caused by whirling end fittings, and the webbing is rewound in a controlled manner.

• the safest and smartest retractable ratchet harness in the world
• the most automatic retractable harness in the world, certified by TÜV / GS
• fast, easy and safe to use
• lockable design > anti-theft protection
• built-in spring automatically retracts the webbing for easy storage
• built-in self-locking mechanism to control the retraction speed
• safety retraction lock when the retraction speed is too fast, the best protection for the user
• strong and abrasion-resistant polyester webbing

druckratschen35-mmhochfester-stahlblau-verzinkt2000-dan-bs
71CSQ051
ABS-Pressure Ratchet 50mm - 50kN (bicolor)
ABS-Pressure Ratchet 50mm - 50kN (bicolor)50 mmHigh tensile steelRAL colour50 kN (5,000 daN)

ABS-Pressure ratchet with Lever lock for 50 mm webbing.
RAL9005 (black)
ABS function – Active Brake System, allows controlled release of preload force.

Why ABS for a pressure ratchet?
Safety comes first. When transporting goods, your secured load can still ‘settle’ or move a little. This is why the load can suddenly start to move uncontrollably when released with a normal pressure or long lever ratchet and possibly cause an accident.
This situation can be prevented with an ABS pressure ratchet (Active Brake System).
An ABS ratchet allows you to release the tension in small steps so that you can react better to a potential problem.

druckratschen50-mmhochfester-stahlral-farbe5000-dan-bs
71CQ057
Pressure Ratchet 50mm - 50kN (309mm)
Pressure Ratchet 50mm - 50kN (309mm)50 mmHigh tensile steelBlue Chromated – KOsil50 kN (5,000 daN)

Long lever-Pressure ratchet with Lever lock for 50 mm webbing.
Toothing: double

In cargo securing, a long lever ratchet refers to a special tool used to tighten cargo on transport vehicles such as trucks, trailers or ships. This tool is used to tighten tension belts or lashing straps with high tension in order to securely fix and secure the cargo during transportation.

A long lever ratchet in cargo securing has a long lever arm that allows the operator to apply a significant tensioning force to the straps. It usually consists of a handle, a long lever and a mechanism that generates the tensioning force. The operator applies the ratchet to the lashing strap and uses the lever to tighten the straps. This allows the load to be securely held in place to prevent slipping or tipping over during transport.

Long lever pressure ratchets are particularly useful when transporting heavy loads or delicate goods where secure fixation and tensioning of the belts is critical. They are often used in the logistics and transport industry to ensure the safety of the load during transport and prevent accidents or damage.

druckratschen50-mmhochfester-stahlblau-verzinkt-kosil5000-dan-bs
71CSQ050
Pressure Ratchet 50mm - 50kN (bicolor)
Pressure Ratchet 50mm - 50kN (bicolor)50 mmHigh tensile steelRAL colour50 kN (5,000 daN)

Pressure ratchet with Lever lock for 50 mm webbing.
RAL9005 (black)

druckratschen50-mmhochfester-stahlral-farbe5000-dan-bs
71CQ055
Pressure Ratchet 50mm - 50kN (170mm)
Pressure Ratchet 50mm - 50kN (170mm)50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

Pressure ratchet with Lever lock for 50 mm webbing.
Handgrip: narrow, plastic

druckratschen50-mmhochfester-stahlblau-verzinkt5000-dan-bs
71CQ100
Pressure Ratchet 50mm - 50kN (FLS)
Pressure Ratchet 50mm - 50kN (FLS)50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

Pressure ratchet FLS with Lever lock for 50 mm webbing.
FLS – fast load securing

druckratschen50-mmhochfester-stahlblau-verzinkt5000-dan-bs
71BQ064
Geared Pull Ratchet 35mm - 30kN (ERGO)
Geared Pull Ratchet 35mm - 30kN (ERGO)35 mmHigh tensile steelBlue Chromated30 kN (3,000 daN)

Geared pull ratchet with Lever lock for 35 mm webbing.
Handgrip: wide, Plastic

35 mm pull ratchet with built-in gearbox for high preload forces. Depending on the lashing belt, STF values of 500 daN can be achieved with ease.

The higher the pre-tensioning force the better the load securing, very high STF values are often required for load securing, our 35 mm ERGO ratchet is therefore equipped with a gearbox.
By means of the gear ratio you can achieve much higher pre-tensioning forces with this ERGO gear ratchet than with a usual ratchet.

ERGO gear ratchet (71BQ064) has a lever lock and is designed for 35 mm lashing straps.

zugratschen35-mmhochfester-stahlblau-verzinkt3000-dan-bs
71CQ060
Pull Ratchet 50mm - 50kN (ERGO, 260mm)
Pull Ratchet 50mm - 50kN (ERGO, 260mm)50 mmHigh tensile steelBlue Chromated – KOsil50 kN (5,000 daN)

Pull ratchet ERGO with Lever lock for 50 mm webbing. Handle length: 260 mm Handgrip: wide, plastic (red)

With the red handle.
Our standard ERGO pull ratchet 71CQ060 finds its use on a truck or van. In combination with webbing and end fittings, it secures your load against slipping and keeps it in the intended place on the loading area. With a lever length of 260 mm, the operation of the long lever ratchet is easier in contrast to a pressure ratchet and a much higher pretensioning force / STF value is achieved.

zugratschen50-mmhochfester-stahlblau-verzinkt-kosil5000-dan-bs
71CQ067
Pull Ratchet 50mm - 50kN (ERGO, 300mm)
Pull Ratchet 50mm - 50kN (ERGO, 300mm)50 mmHigh tensile steelBlue Chromated – KOsil50 kN (5,000 daN)

Long lever Pull ratchet ERGO with Lever lock for 50 mm webbing.
Handle length: 300 mm
Handgrip: PE, red

One of the common clamping elements for heavy goods is a pull ratchet, this is also called ERGO ratchet. In contrast to a push ratchet / short lever ratchet, this is more ergonomic for the user. When lashing and tensioning, the lever, as the name of the ratchet already says, is pulled (down) and not pressed, this protects the spine of the user. Another advantage is that higher pretensioning forces – STF (Standard Tension Force) can be achieved here when securing the load.

zugratschen50-mmhochfester-stahlblau-verzinkt-kosil5000-dan-bs
71CQ068
71CQ068-Ergo-Langhegel-Zugratsche
Pull Ratchet 50mm - 50kN (ERGO, 340mm)50 mmHigh tensile steelBlue Chromated – KOsil50 kN (5,000 daN)

Long lever Pull ratchet ERGO with Lever lock for 50 mm webbing.
Handle length: 340 mm
Handgrip: PE, red

An “ergo ratchet for load securing” is a special type of ratchet designed for securing cargo on trucks, trailers or other means of transport. These ratchets are designed to tighten tie-down straps or lashing straps to ensure that the transported load remains secure and stable during transportation.
In general, ERGO ratchets for load securing are designed to be easily and efficiently used by operators. They often feature longer handles that allow for comfortable handling to ease the process of pulling and tightening the straps. This can help reduce operator strain and fatigue during the load securing process.
The use of ergonomic ratchets for load securing is important to ensure safety on the road and to ensure that the load does not slip or become damaged during transport. These ratchets are available in various sizes and designs to meet different load securing requirements.

zugratschen50-mmhochfester-stahlblau-verzinkt-kosil5000-dan-bs
71CQ063
ABS-Pull Ratchet 50mm – 50kN (ERGO)
ABS-Pull Ratchet 50mm – 50kN (ERGO)50 mmHigh tensile steelBlue Chromated – KOsil50 kN (5,000 daN)

ABS-ERGO pull ratchet with lever lock for 50 mm lashing strap.
Handle design: wide, steel
Active Brake System (ABS): enables controlled release of the pre-tensioning force.

zugratschen50-mmhochfester-stahlblau-verzinkt-kosil5000-dan-bs
71CSQ063
ABS-Pull Ratchet 50mm – 50kN (ERGO, bicolor black)
ABS-Pull Ratchet 50mm – 50kN (ERGO, bicolor black)50 mmHigh tensile steelRAL colour50 kN (5,000 daN)

ABS-ERGO Pull ratchet with Lever lock for 50 mm webbing.
RAL9005 (black)
Handgrip: wide, steel
ABS function – Active Brake System, allows controlled release of preload force.

zugratschen50-mmhochfester-stahlral-farbe5000-dan-bs
71CQ064
Geared Pull Ratchet 50mm - 50kN (ERGO)
Geared Pull Ratchet 50mm - 50kN (ERGO)50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

Geared pull ratchet with Lever lock for 50 mm webbing.
Handgrip: wide, Plastic

50 mm pull ratchet with built-in gearbox for high preload forces. Depending on the lashing belt, STF values of 800 daN can be achieved with ease.

The decisive factor for good load securing is the pretensioning force to be achieved, depending on the application, very high STF values are required for load securing, our ERGO long lever ratchet is equipped with a gearbox.
Due to the gear ratio, you can achieve much higher STF values with this ERGO gear ratchet than with a usual ERGO long lever pull ratchet at the pre-tensioning force. Our ERGO gear ratchet (71CQ064) has a lever lock and is designed for 50 mm lashing straps.

zugratschen50-mmhochfester-stahlblau-verzinkt5000-dan-bs
74CQ000
Pressure Ratchet 50mm - 50kN (alu, Swivel Hook Set)
Pressure Ratchet 50mm - 50kN (alu, Swivel Hook Set)50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

Pressure ratchet with Lever lock for 50 mm webbing.
Swivel Hook: mounted
Handgrip: Aluminium

Set:

druckratschen50-mmhochfester-stahlblau-verzinkt5000-dan-bs
74CQ001
Pressure Ratchet 50mm - 50kN (Swivel Hook Set)
Pressure Ratchet 50mm - 50kN (Swivel Hook Set)50 mmHigh tensile steelBlue Chromated – KOsil50 kN (5,000 daN)

Pressure ratchet set with lever safety device for 50 mm lashing strap
Swivel hook: mounted

Set:

druckratschen50-mmhochfester-stahlblau-verzinkt-kosil5000-dan-bs
74CQ002
Pressure Ratchet 50mm - 50kN (J-Hook Set)
Pressure Ratchet 50mm - 50kN (J-Hook Set)50 mmHigh tensile steelBlue Chromated – KOsil50 kN (5,000 daN)

Pressure ratchet set with Lever lock for 50 mm webbing.
J-Hook / Finger hook: mounted

Set:

druckratschen50-mmhochfester-stahlblau-verzinkt-kosil5000-dan-bs
74CQ003
ABS-Pressure Ratchet 50mm – 50kN (J-Hook Set)
ABS-Pressure Ratchet 50mm – 50kN (J-Hook Set)50 mmHigh tensile steelHDPD - black50 kN (5,000 daN)

ABS-Pressure ratchet set with Lever lock for 50 mm webbing.
J-Hook / Finger hook: mounted

druckratschen50-mmhochfester-stahlhdpd-schwarz5000-dan-bs
74CQ004
Pressure ratchet 50mm - 50kN (Swivel hook Set)
Pressure ratchet 50mm - 50kN (Swivel hook Set)50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

Pressure ratchet – set with rubberized handle and lever lock for 50 mm lashing strap
Swivel hook: mounted

Set:

Discover our pressure ratchet with an integrated swivel hook – the perfect solution for effortless tensioning of 50 mm webbing! With a breaking load of 50 kN, our pressure ratchet is reliable and safe, even under extreme conditions.
The rubberised handle and lever lock make operating the ratchet child’s play. Tensioning belts has never been so convenient. The high-quality workmanship ensures a long service life and maximum performance.
Our pressure ratchet with swivel hook is your reliable partner for safe and easy tensioning.

druckratschen50-mmhochfester-stahlblau-verzinkt5000-dan-bs
71DQ101
Heavy Duty Pressure ratchet 75mm - 100kN
Heavy Duty Pressure ratchet 75mm - 100kN75 mmHigh tensile steelBlue Chromated – KOsil100 kN (10,000 daN)

Heavy Duty Pressure ratchet without Lever lock for 75 mm webbing.

Heavy-duty pressure ratchets are not suitable for tie-down lashing, they are used exclusively for direct lashing and the STF value is not shown on the lashing strap label.

druckratschen75-mmhochfester-stahlblau-verzinkt-kosil10000-dan-bs
71DX101
Heavy Duty Pressure Ratchet 75mm - 70kN (Inox)
Heavy Duty Pressure Ratchet 75mm - 70kN (Inox)75 mmInox70 kN (7,000 daN)

Stainless steel pressure ratchet ensures the securing of heavy loads.
To be used load securing straps with a width of 75 mm.

Heavy-duty pressure ratchets are not suitable for tie-down lashing, they are used exclusively for direct lashing and the STF value is not shown on the lashing strap label.

druckratschen75-mmedelstahl7000-dan-bs
71DQ064
Geared Pull Ratchet 75mm - 100kN (ERGO)
Geared Pull Ratchet 75mm - 100kN (ERGO)75 mmHigh tensile steelBlue Chromated100 kN (10,000 daN)

75mm gear pull ratchet with built-in gear for high pretensioning forces. Depending on the lashing strap, STF values of 500 daN are easily achieved.
Handle design: wide, plastic

The decisive factor for good load securing is the pretensioning force to be achieved, depending on the application, very high STF values are required for load securing, our ERGO long lever pull ratchet is equipped with a gear.
Due to the gear ratio, you can achieve much higher STF values with this ERGO gear ratchet than with a usual ERGO long lever pull ratchet at the pre-tensioning force. Our ERGO gear ratchet (71DQ064) has a lever lock and is designed for 75 mm lashing straps.

zugratschen75-mmhochfester-stahlblau-verzinkt10000-dan-bs
71DQ102
Tree trunk press / HD Pressure ratchet 75mm - 100kN
Tree trunk press / HD Pressure ratchet 75mm - 100kN75 mmHigh tensile steelBlue Chromated100 kN (10,000 daN)

Tree trunk press / Heavy Duty Pressure ratchet for 75 mm webing.
With opening for Handle 71DQ103.

A tree trunk press equipped with a 75 mm wide tensioning belt is used for securing tree trunks. It prevents tearing during felling or further processing. The log press is placed above the cut and always opposite the felling notch.

druckratschen75-mmhochfester-stahlblau-verzinkt10000-dan-bs
71DQ500
Heavy Duty Pressure ratchet 100mm - 100kN
Heavy Duty Pressure ratchet 100mm - 100kN100 mmHigh tensile steelBlue Chromated100 kN (10,000 daN)

Heavy duty pressure ratchet for 100 mm lashing straps – steel version

A heavy-duty pressure ratchet is a tool used to secure and tension heavy loads. It consists of a ratchet mechanism, which is driven by a lever, and a stop shoe, which is pressed against the load. It allows loads to be secured and tensioned with great force.
The process of using a heavy duty compression ratchet is as follows:
1. position the heavy duty pressure ratchet at the desired location.
2. operate the lever to actuate the ratchet mechanism and secure the load.
3. when the desired tensioning force is reached, close the lever and the load will remain securely held.
4. to release the tension, open the lever to release the ratchet mechanism.
It is important to note that the maximum tensioning force that can be applied to the heavy duty ratchet depends on the type and size of the heavy duty ratchet. It is therefore important to follow the manufacturer’s instructions and ensure that it is suitable for the intended application.

druckratschen100-mmhochfester-stahlblau-verzinkt10000-dan-bs
72AS000
Buckle 25mm - 10kN (black)
Buckle 25mm - 10kN (black)25 mmHigh tensile steelCathodic dip coating (KTL) black10 kN (1,000 daN)

Buckle for 25 mm Lashing.
RAL 9005 – black

bandbuegel25-mmhochfester-stahlktl-beschichtet-schwarz1000-dan-bs
72ASQ022
Buckle 25mm - 6kN (black)
Buckle 25mm - 6kN (black)25 mmHigh tensile steelRAL colour6.0 kN (600 daN)

Buckle for 25 mm Lashing.
RAL 9005 – black

schnallen-und-endbeschlaege25-mmhochfester-stahlral-farbe600-dan-bs
72AQ021
Double buckle 25mm - 10kN (bended)
Double buckle 25mm - 10kN (bended)25 mmHigh tensile steelBlue Chromated10 kN (1,000 daN)

Double buckle bended, for 25 mm Lashing belt, without hook.

25-mmhochfester-stahlblau-verzinkt1000-dan-bs
72ZQ002
Airline fitting / Single-Stud fitting - 18kN
Airline fitting / Single-Stud fitting - 18kNn/aCombinationCombination18 kN (1,800 daN)

Airline fitting / Single stud fitting, with Inox Ring.

Airline fitting with a stainless steel ring for airline rail/lashing rails.

Load securing in a box van
Airline fitting with a stainless steel ring as a connection between lashing straps and airline rails / airline guide rails.

– Compatible with all single airline guide rails
– Safe and quick installation
– High quality materials
– one-handed operation

schnallen-und-endbeschlaegen-vkombinationkombination1800-dan-bs
72FQ003
Airline fitting / Double-Stud fitting - 20kN
Airline fitting / Double-Stud fitting - 20kNn/aHigh tensile steelBlue Chromated20 kN (2,000 daN)

Airline fitting / Double stud fitting.
End terminal without Ring
Stamp: ISO 9788

Airline fitting for airline rail/lashing rails.

schnallen-und-endbeschlaegen-vhochfester-stahlblau-verzinkt2000-dan-bs
72FQ004
Airline fitting / Double stud fitting - 22.5kN (with Ring)
Airline fitting / Double stud fitting - 22.5kN (with Ring)n/aHigh tensile steelBlue Chromated22.5 kN (2,250 daN)

Airline fitting / Double stud fitting, with Ring.
Norm: ISO 9788

Airline fitting with ring (Double-Stud Fitting with ring) for the Airline rails.
The Airline fitting is inserted into the rail at any point and moved to the grid dimension, thereby the bolt locks automatically. A snap hook, pointed hook for load securing can be attached to the integrated ring.

schnallen-und-endbeschlaegen-vhochfester-stahlblau-verzinkt2250-dan-bs
72BQ008
Double buckle 40mm - 50kN
Double buckle 40mm - 50kN35 mm, 40 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

Double buckle for 35 mm up to 40 mm Lashing straps.

schnallen-und-endbeschlaege35-mm 40-mmhochfester-stahlblau-verzinkt5000-dan-bs
72CQ030
Clamping buckle 50mm - 6.0kN
Clamping buckle 50mm - 6.0kN50 mmHigh tensile steelBlue Chromated6.0 kN (600 daN)

Clamping buckle / Sliding buckle for 50 mm Lashing belt.

Clamping buckle / Sliding buckle adjustable.
Range of use 50 mm webbing

schnallen-und-endbeschlaege50-mmhochfester-stahlblau-verzinkt600-dan-bs
72CQ010
End terminal 50mm - 20kN
End terminal 50mm - 20kN50 mmHigh tensile steelBlue Chromated20 kN (2,000 daN)

Simple lashing to combination lashing rails is made possible by the anchor rail fitting for 50 mm lashing straps.
Our lashing rail fittings have a breaking load of 2,000 daN.

schnallen-und-endbeschlaege50-mmhochfester-stahlblau-verzinkt2000-dan-bs
72CQ032
End fitting 50mm - 18kN
End fitting 50mm - 18kN50 mmHigh tensile steelBlue Chromated18 kN (1,800 daN)

End fitting / Buckle for 50 mm Lashing straps.
Deflector fitting

schnallen-und-endbeschlaege50-mmhochfester-stahlblau-verzinkt1800-dan-bs
72CQ025
Double buckle 50mm - 20kN
Double buckle 50mm - 20kN50 mmHigh tensile steelBlue Chromated20 kN (2,000 daN)

Double buckle / Flat buckle for 50 mm Lashing belt.

schnallen-und-endbeschlaege50-mmhochfester-stahlblau-verzinkt2000-dan-bs
72CS000
Double buckle 50mm - 20kN (bended)
Double buckle 50mm - 20kN (bended)50 mmHigh tensile steelRAL colour20 kN (2,000 daN)

Double buckle bended, for 50 mm Lashing belt, without hook.
RAL9005 (black)

schnallen-und-endbeschlaege50-mmhochfester-stahlral-farbe2000-dan-bs
72CQ037
Double buckle 50mm - 25kN
Double buckle 50mm - 25kN50 mmHigh tensile steelBlue Chromated25 kN (2,500 daN)

Double buckle for 50 mm Lashing belt, without hook.

To use this bar closure is also called sliding buckle with a webbing of max. 50 mm width.

schnallen-und-endbeschlaege50-mmhochfester-stahlblau-verzinkt2500-dan-bs
72CQ034
Hook for Krone-System 50mm - 40kN
Hook for Krone-System 50mm - 40kN50 mmHigh tensile steelBlue Chromated40 kN (4,000 daN)

Hook for 50 mm Webbing.
Endfitting with Hook for KRONE Trailers and Profi Liner.

flachhaken schnallen-und-endbeschlaege50-mmhochfester-stahlblau-verzinkt4000-dan-bs
72CQ019
Double buckle 50mm - 50kN
Double buckle 50mm - 50kN50 mmHigh tensile steelBlue Chromated50 kN (5,000 daN)

Double buckle for 50 mm Lashing belt.

A double buckle is required for cargo securing where lash straps are used.

schnallen-und-endbeschlaege50-mmhochfester-stahlblau-verzinkt5000-dan-bs
72FQ002
U-Bolt 35mm - 40kN (Premounted plate)
U-Bolt 35mm - 40kN (Premounted plate)n/aHigh tensile steelBlue Chromated40 kN (4,000 daN)

U-Bolt with plate and locknuts, for 35 mm webbing.
Angled 150°, Ø 12 mm

– Lashing bracket/u-bolt, 50 x 87 mm, screw connection M 12
– cranked outer width 62 mm
– inner width 38 mm
– Length 87 mm
– 2 self-locking nuts M 12 mounted

zurrmulden-und-buegeln-vhochfester-stahlblau-verzinkt4000-dan-bs
72FQ001
D-Ring with bracket - 16kN
D-Ring with bracket - 16kNHigh tensile steelBlue Chromated16 kN (1,600 daN)

D-Ring with mounting bracket.

Large D-Ring with bracket for better load securing.
Subsequent screwing on the vehicle floor or on the vehicle walls.

zurrmulden-und-buegelhochfester-stahlblau-verzinkt1600-dan-bs
72ZQ004
Anchoring Fitting - 25kN
Anchoring Fitting - 25kNHigh tensile steelBlue Chromated25 kN (2,500 daN)

Oval Anchoring Fitting Single
Length x Width x Height: 145 x 100 x 16 mm

zurrmulden-und-buegelhochfester-stahlblau-verzinkt2500-dan-bs
72KB000
Clamp Bar
Clamp Barn/aAluminiumBlanc

Clamp Bar / Clamping board with extendable aluminium plates.
Adjustable Length: 2.40 – 2.70 m
Breaking Load (BL): 420 daN

Clamp bar are placed on the dropside and secure the load against slipping and tipping.
The intermediate wall fasteners are made of aluminum, the tensioning on the dropside is done by means of rubberized levers.

With a clamping board you have an additional tool to fix the load.

ladungssicherung-weiteresn-valuminiumblank
72CQ040
Panel Clip 50mm
Panel Clip 50mm50 mmHigh tensile steelBlue Chromated

Panel Clip for board thickness 10 – 45 mm.

Our board wall clamp 72CQ040 allows smaller loads to be quickly secured to a board wall, e.g. on a flatbed vehicle. No lashing points are required for secure fastening, it can be used at any point, the dropside should be between approx. 10 – 45 mm thick. The rubberized contact surfaces prevent damage to the dropside.

ladungssicherung-weiteres50-mmhochfester-stahlblau-verzinkt
71DQ103
Lever for Tree trunk press
Lever for Tree trunk pressn/aHigh tensile steelTransparent Passivated

Handle for Tree trunk press 71DQ102.
Length: 420 mm

ladungssicherung-weiteresn-vhochfester-stahltransparent-passiviert
72ED002
Trapezium Canvas Runner
Trapezium Canvas Runnern/aHigh tensile steelZinc Yellow Passivated

Canvas runner trapezium with 2 white B30S roles (with bearing).

Our tarpaulin rollers:

  • Very good rolling properties
  • Versions for different systems available
  • KONNEX quality
zubehoer-fuer-lkw-planenn-vhochfester-stahlgelb-verzinkt
72ED003
Canvas Runner
Canvas Runnern/aSteelZinc Yellow Passivated

Canvas runner wide with 2 B30S roles (with bearing).

zubehoer-fuer-lkw-planenn-vnormalstahlgelb-verzinkt
72FQ008
Canvas runner (2 roles)
Canvas runner (2 roles)n/aHigh tensile steelZinc Yellow Passivated

Canvas runner with 2 white roles (with Bearing)

Dekra-Certifikate

Certificate regarding the strenght testing of aids for load securing according to the DEKRA requirements profile VA 80-13-TTD-50 for sliding curtains and DIN EN 12641-2 minimum requirement sliding curtains.

zubehoer-fuer-lkw-planenn-vhochfester-stahlgelb-verzinkt
72YP000
Safety unit for custom canvas (TIR)
Safety unit for custom canvas (TIR)n/aCombinationCombination

Safety unit for custom canvas (TIR)
TIR – Transports Internationaux Routiers
Bolt: steel galvanized
Nut + sleeve: Inox – 1.4301 / AISI 304

zubehoer-fuer-lkw-planenn-vkombinationkombination
72YP004
Blocking Unit Ø12
Blocking Unit Ø12n/aAluminiumBlanc

Blocking unit with security grub screw
Aluminium unit: 16 mm x Ø12 mm
VA screw: M6 x 16 mm

For tarpaulins and awnings, the kedder/blocking unit is held in the correct position.
Fastening by means of SW 3.

zubehoer-fuer-lkw-planenn-valuminiumblank

In our range you will find a large number of high-quality and high-quality items that are essential to secure a load according to regulations. We have the right end fittings for every strap width, such as E.g .: claw hooks, triangles and snap hooks. You can also expect a very large selection of selected products for ratchets. Regardless of whether it is a push or pull ratchet, we offer you many alternatives. Should it be a short-lever ratchet or a long-lever ratchet? You decide for yourself … and to make it as easy as possible for you to find it, the search function gives you many filter options so that you can find your desired product quickly and reliably. However, if you find that the item you are looking for cannot be found in our product selection, please do not hesitate to contact us. We would be happy to make you a personal offer.

© KONNEX GmbH 2017 – 2024
