71CSQ063

ABS-Pull Ratchet 50mm – 50kN (ERGO, bicolor black)

ABS-ERGO Pull ratchet with Lever lock for 50 mm webbing.
RAL9005 (black)
Handgrip: wide, steel
ABS function – Active Brake System, allows controlled release of preload force.

Webbing width

Material

Finishing

Lever lock

present

Tested according

DIN EN 12195-2

Breaking Strength (BS)

50 kN (5,000 daN)

Lashing Capacity (LC)

25 kN (2,500 daN)

STF-value *

450 daN

Why ABS? It’s as simple as it is obvious.
It’s about your safety, because when transporting goods, your secured load can still ‘settle’ or move a little. This is why the load can suddenly start to move uncontrollably when released with a normal pressure or ERGO long lever ratchet and possibly cause an accident.
This situation can be prevented with an ABS (Active Brake System) towing ratchet.
An ERGO ABS long-lever ratchet allows you to release the tension in small steps so that you can react better to a potential problem.
Our ABS-EGRO ratchets are tested in accordance with DIN EN 12195-2 for the prescribed lashing capacity (LC) and breaking load (BL).

Weight per piece: 2.19 kg
Box (8 pieces): 18.02 kg

Download pdf

Download pdf

* Important note on the STF - preload force: The STF-value we specify for pull and pressure ratchets is for guidance only.
Read more

Delivery quantity: 8 Pieces

Usually ready for shipment in 1 to 3 working days.

SKU: 71CSQ063 Category: Tags: ,
