71CQ067

Pull Ratchet 50mm – 50kN (ERGO, 300mm)

Long lever Pull ratchet ERGO with Lever lock for 50 mm webbing.
Handle length: 300 mm
Handgrip: PE, black

Webbing width

50 mm

Material

High tensile steel

Finishing

Blue Chromated – KOsil

Lever lock

present

Tested according

DIN EN 12195-2

Breaking Strength (BS)

50 kN (5,000 daN)

Lashing Capacity (LC)

25 kN (2,500 daN)

STF-value *

550 daN

One of the common clamping elements for heavy goods is a pull ratchet, this is also called ERGO ratchet. In contrast to a push ratchet / short lever ratchet, this is more ergonomic for the user. When lashing and tensioning, the lever, as the name of the ratchet already says, is pulled (down) and not pressed, this protects the spine of the user. Another advantage is that higher pretensioning forces – STF (Standard Tension Force) can be achieved here when securing the load.

Weight per piece: 2.19 kg,
Box (8 pieces): 18.02 kg,
Pallet (48 boxes = 384 pieces): 884.96 kg,
Height pallet: 110 cm (4 layers of 12 boxes)

Download pdf

* Important note on the STF - preload force: The STF-value we specify for pull and pressure ratchets is for guidance only.
Read more

Delivery quantity: 8 Pieces

Usually ready for shipment in 1 to 3 working days.

Price on request

SKU: 71CQ067 Category: Tag:
