Pressure Ratchet 50mm – 50kN (188mm)

The one with the red handle – our standard pressure ratchet with lever lock for 50 mm lashing strap.
Handle design: plastic, red
Lever length: 188 mm

Webbing width

50 mm


High tensile steel


Blue Chromated – KOsil

Lever lock


Tested according

DIN EN 12195-2

Breaking Strength (BS)

50 kN (5,000 daN)

Lashing Capacity (LC)

25 kN (2,500 daN)

STF-value *

300 daN

Our standard pressure ratchet 71CQ050 is used on a truck or van. In connection with belt strap and end fittings, it secures your load against slipping and holds it in the intended place on the loading area.

Our quality and its strengths:
  • Ergonomically shaped, red handle
  • No rivets or end caps on the handle prevent the risk of injury
  • Band take-up shaft made of very high quality steel with anti-slip (AS)
  • Disc and sprocket combined, no additional disc required
  • Specially shaped sprocket for better stability of the belt take-up shaft
  • Including lever lock, optimized movement
  • Specially durable KOsil coating: increased resistance to RR according to ISO 9227 NSS test
  • Best price/performance ratio
  • Quality at the highest level, guaranteed by ISO 9001 and ISO 14001
  • Multiple times tested according to DIN EN 12195-2, system certified by TÜV and DGUV

Weight per piece: 0,86 kg,
Box (20 pieces): 17.7 kg,
Pallet (40 boxes = 800 pieces): 728.0 kg,
Height pallet: 110 cm (5 layers of 9 boxes)

Download pdf

Download leaflet: 71CQ050 – the one with the red handle

* Important note on the STF - preload force: The STF-value we specify for pull and pressure ratchets is for guidance only.
Read more

Delivery quantity: 20 Pieces

Usually ready for shipment in 1 to 3 working days.

Price on request

SKU: 71CQ050 Category:
