72CQ033

Swivel J-Hook 50mm – 50kN (105mm)

Swivel Hook for 50 mm Ratchet, without bolt. Length: 105 mm

Webbing width

Material

Finishing

Tested according

DIN EN 12195-2

Breaking Strength (BS)

50 kN (5,000 daN)

Lashing Capacity (LC)

25 kN (2,500 daN)

A swivel hook is a hook that can rotate on its own axis. This rotating function prevents connected ropes, chains or belts from twisting or tangling, which is particularly important when securing loads.
1. avoidance of twisting – The ability to rotate allows the load to move to a certain extent without the lashing equipment (e.g. tension belts or chains) twisting or becoming excessively stressed.
2. even force distribution – A swivel hook ensures that the tensile forces are optimally distributed, which increases the stability of the load.
3. increased safety – less twisting means less tension on the lashing equipment, reducing the risk of material fatigue or failure.

Weight per piece: 0,32 kg
Box (20 pieces): 6,5 kg

Download pdf

Delivery quantity: 20 Pieces

Usually ready for shipment in 1 to 3 working days.

SKU: 72CQ033 Category:
