72CQ003

J-Hook 50mm – 50kN (74mm)

J-Hook / Double finger hook short, for 50 mm Lashing belt. Length: 74 mm

Webbing width

Material

Finishing

Tested according

DIN EN 12195-2

Breaking Strength (BS)

50 kN (5,000 daN)

Lashing Capacity (LC)

25 kN (2,500 daN)

A j-hook is used in load securing to ensure a stable and secure connection between the load and the transportation surface (e.g. a truck or trailer floor). The main function of the pointed hook is to enable a fastening or lashing system by connecting it to lashing straps.
How it works:
1. fastening the lashing straps or chains: The pointed hook is attached to a stable point on the loading surface or to the load itself. It is generally used to connect lashing straps or chains to the corresponding ratchets.
2. lashing the load: By using lashing straps connected to the pointed hook, the load can be fixed and held in position. The hook itself helps to control the tension of the straps and ensure that the load does not slip during transportation.
3. preventing movement: The pointed hook helps to secure the load against lateral movement, vibrations and shocks during transportation, which is particularly important with long or heavier loads.
Advantages:
– Effective securing: the pointed hook ensures a robust connection and reduces the risk of the load slipping or coming loose during transportation.
– Simplicity and flexibility: The hook is easy to handle and can be attached to different points on the loading area as required.
– Versatility: Pointed hooks are available in various

Weight per piece: 0,23 kg
Box (100 pieces): 23.5 kg

Download pdf

Download pdf

Delivery quantity: 100 Pieces

Usually ready for shipment in 1-3 working days (depending on stocklevel).

SKU: 72CQ003 Category:
